W6102 SMT Stencil Wiping Rolls

Name: W6102 SMT Stencil Wiping Rolls
SKU: WPC-420
Availability: InStock

Material: Cellulose/Polyester

Size: Others

Edge Type: Cut Edge

Color: White

Type: SMT Stencil Wiping Rolls

Used for wiping and cleaning the stencil of MPM screen printers.

Notches: No
Ribs: 12
Material Weight: 56 g/m2
Material Width: 300mm
Material Length: 10m
Core ID: 19.5mm
Core Length: 455mm
Core Material: Plastic
packaged in 50 rolls/box

Request for Quote

Product Overview & Guides

WIPESTAR's SMT printer cleaning series is perfectly compatible with various brands and models of printer stencil wiping needs. We choose materials for the wiping cloth that have low linting properties and leave minimal dust after wiping. They effectively clean surfaces, have high dry and wet strength, and can be used with solvents.

MPM Stencil Wiping Rolls with plastic cores have 12 internal ribs.

MPM Series Specifications (Core ID×Core Length×Material Width×Material Length):

Model W6101: Φ19.5mm×455mm×250mm×10m

Model W6102: Φ19.5mm×455mm×300mm×10m

Model W6103: Φ19.5mm×455mm×330mm×10m

Model W6104: Φ19.5mm×455mm×350mm×10m

Model W6105: Φ19.5mm×455mm×400mm×10m

Product Features

● Unique Processing
Made from natural cellulose and high-quality materials, processed using a unique spunlace method, forming a distinctive 2-ply structure of cellulose and polyester.
● PVC Core Tube
The inner and outer walls of the core tube are smooth and even, easy to position, and do not loosen during cleaning. It has high impact strength and superior quality.
● Strong Absorption and Cleaning Power
The paper is smooth and leaves no traces on PCB board stains. It has high water and oil absorption capacity and excellent cleaning ability.
● Low Lint
Strong and durable, with extremely low dust and lint production.

Specifications

Model	Weight	Material	Size	Pattern	Structure	Color	Packaging	Edge	Shipping
W6102	56 GSM	55%Cellulose/45%Polyester Core Material: Plastic	Material Width: 300mm Material Length: 10m Core ID: 19.5mm Core Length: 455mm	Plain	Spunlace	White	Perforated roll	Cold cut	15 rolls/box

Model

W6102

Weight

56 GSM

Material

55%Cellulose/45%Polyester
Core Material: Plastic

Size

Material Width: 300mm
Material Length: 10m
Core ID: 19.5mm
Core Length: 455mm

Pattern

Plain

Structure

Spunlace

Color

White

Packaging

Perforated roll

Edge

Cold cut

Shipping

15 rolls/box

Model	Weight	Material	Size	Pattern	Structure	Color	Packaging	Edge	Shipping
W6102	56 GSM	55%Cellulose/45%Polyester Core Material: Plastic	Material Width: 300mm Material Length: 10m Core ID: 19.5mm Core Length: 455mm	Plain	Spunlace	White	Perforated roll	Cold cut	15 rolls/box
